Waterproof
Anti-interference
Heat Dissipation
Corrosion Resistance
Lightning Protection
Dustproof
Stable
Modular installation
| Technical Feature | Specifications & Performance (Max3308R) |
| Model | GL-Max3308R (IoT Cloud-Integrated Version) |
| IoT Architecture | Built-in Intelligent Enterprise Gateway for deep cloud platform pairing |
| Cloud Functionality | Remote real-time telemetry, advanced load on/off control, and over-the- |
| PoE Matrix Output | 8× 100/1000M Base-TX RJ45 Ports | 90W Max per port (IEEE 802.3bt) |
| PoE Long-Run | High-frequency short-circuit & surge-protected power runs up to 150 meters |
| Native DC Terminals | DC 12V 5A (60W) | DC 24V 5A (120W) via industrial 2P 7.62 connectors |
| Critical Backup EPS | DC 12V 3A (36W) Dedicated Uninterrupted EPS Port for critical communications |
| Storage Core | High-capacity Automotive-Grade Ternary Lithium Pack (24V 135Ah / 24V 126Ah) |
| Network Switching | 20G Non-blocking Backplane Bandwidth | 15 Mbps Forwarding Rate | 4K MAC Address |
| Housing & Rating | Premium Full Aluminum Enclosure with Heavy-Duty Security Locks | IP55 Rated |
| Global | Fully Compliant with CE, FCC, RoHS | Battery: UN38.3 & MSDS Certified |
1. Built-in Smart Gateway for Deep Cloud Orchestration
Unlike traditional systems that require external dongles or complex networking setups, the Max3308R features a natively integrated IoT Smart Gateway. It automatically syncs with the IoT Cloud Management Platform via 4G/5G wireless networks, providing localized intelligence and instant wide-area communication.
2. Comprehensive Cloud Telemetry & Analytics
Get deep operational insights without ever setting foot on-site. The centralized cloud platform displays full-stack real-time telemetry:
Energy Analytics: Track real-time solar input voltage, charging current, daily power generation, and cumulative yield.
Battery Diagnostics: Monitor absolute battery voltage, real-time temperature, and exact SOC (State of Charge) percentage.
System Health Logs: Receive instant cloud alerts for PV over-voltage, load short circuits, over-current, and abnormal NTC collection states.
3. Remote Edge Reboot & Power Control
Drastically cut down truck-roll expenses and maintenance overhead. If a connected device hangs or drops offline, engineers can access the Web Dashboard or Mobile App to remotely cycle power or turn individual load outputs ON/OFF. This provides instant remote reboots and smooth operation for edge hardware located in hard-to-reach spaces.
4. Intelligent Low-Light Power Amplication
Real Online MPPT: Automatically locks onto the maximum power point of the solar panel, increasing low-light charging capacity by up to 25%.
Synchronous PV-Battery Hybrid Discharge: During overcast days or weak light conditions, the algorithm blends solar and battery energy simultaneously to power the load, dramatically extending the life of your battery storage.
Delayed Smart Activation Circuit: Implements delayed startup algorithms during dawn/early morning, avoiding equipment damage caused by repetitive power cycling and low-voltage spikes.
5. Next-Gen Modular Hardware Architecture
Protected by a low-power, robust full aluminum alloy housing utilizing forced air cooling and 10-layer heavy-duty embedded safety protocols. Inside, the system provides integrated SMA internal-to-external feeders to house optional 4G/5G edge routers and dual-band Wi-Fi transceivers, completely mitigating internal chassis signal attenuation.
Engineered for Customization & Secondary B2B Development
The Max3308R functions as an open, standardized edge computing and power networking matrix for global enterprise infrastructure:
Protocol & API Integration: Standard RS485 data ports running Modbus RTU protocols alongside open IIC/485 docking layers for secondary hardware/software development.
Software White-Labeling: Custom software platform dashboards, dedicated Mobile APPs, mini-programs, and H5 cloud front-ends tailored to your brand identity.
Chassis & Precision CNC Customization: Engineered with an aluminum alloy or heavy-duty stainless steel build, tailored surface laser engraving, UV high-definition color printing, and customized cable routing placements.
Advanced Field Add-ons: Space allocated for embedding rack-mounted 4-port fiber optic terminal boxes, 500W pure sine wave inverters (AC 110V–240V output), custom-heated battery jackets for freezing zones (down to $-15℃), or PoE sound-and-light strobe warning sirens.
Application Environments
The ultimate smart power architecture for automated, unmanned remote installations:
Smart Cities & AI Edge Systems: Automated drone (UAV) docking stations, municipal public broadcasting hubs, and traffic AI speed systems.
Critical Telecom Infrastructure: Remote 4G/5G LTE cellular relays, edge computing nodes, and off-grid IoT routing arrays.
Industrial Monitoring Networks: Unattended petroleum/gas pipelines, hydrological data collection, forest fire AI detection, and remote border security monitoring.
